在全球氣候變暖的當下，空調在白色家電中占有舉足輕重的地位。典型的空調系統由室外機、室內機和電源單元組成。對于電源單元，捷捷微電 具有高隔離電壓光電耦合器，用于隔離 PWM 和 PFC。對于室內機，MCU 控制與光電耦合器結合的風扇模塊、與光電三端雙向可控硅開關和外圍設備結合的加熱器開關。主隔離 MCU 和相關外圍設備，確保電路的可靠性。對于室外機，使用 MCU 控制風扇和壓縮機的電機系統。電機控制系統是各種家用電器的組成部分。每一個單獨模塊都取決于安全和環境保護要求、性能要求，當然還有制造成本。因此，在設計家用電器時，需要加強對單片機和外圍設備對應用電路的隔離，以確保電路的低噪聲。
| Product Name |
IT(RMS)_Max(A) | ITSM_Max (A) |
VDRM / VRRM_Max(V) | IGT_I_Max(mA) | IGT_II_Max(mA) | IGT_III_Max (mA) | IGT_IV_Max(mA) | TJ (°C) | JJM Package |
|---|
| JST131U-800D | 1 | 16 | 800 | 5 | 5 | 5 | 10 | 125 | TO-92 |
|---|
| JST137C-800E | 8 | 65 | 800 | 10 | 10 | 10 | 25 | 125 | TO-220C |
|---|
| Product Name | Rank | CTR_Min (%) |
CTR_Max (%) |
IF_Max(mA) | VR_Max(A) | VCEO_Max(V) | VISO_Max(VRMS) | JJMPackage |
|---|
| JOC816X1 | A | 80 | 160 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| B | 130 | 260 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| C | 200 | 400 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| D | 300 | 600 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| JOC817X1 | - | 50 | 600 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| A | 80 | 160 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| B | 130 | 260 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| C | 200 | 400 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| D | 300 | 600 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| E | 100 | 200 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| JOC101X | 1010 | 300 | 600 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1015 | 50 | 150 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1016 | 100 | 300 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1017 | 80 | 160 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1018 | 130 | 260 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1019 | 200 | 400 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1011 | 60 | 300 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1012 | 63 | 125 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1013 | 100 | 200 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1014 | 160 | 320 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1012 | 22 | - | 1 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1013 | 34 | - | 1 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1014 | 56 | - | 1 | 6 | 80 | 5000 | LSOP-4 |
|---|
| Product Name |
IT(RMS)_Max(A) | ITSM_Max(A) | VDRM_Min / VRRM_Max(V) | IGT_I_Max(mA) | IGT_II_Max(mA) | IGT_III_Max (mA) | IGT_IV_Max(mA) | TJ (°C) | JJM Package |
|---|
| JST131U-800D | 1 | 16 | 800 | 5 | 5 | 5 | 10 | 125 | TO-92 |
|---|
| JST137C-800E | 8 | 65 | 800 | 10 | 10 | 10 | 25 | 125 | TO-220C |
|---|
| Product Name |
Variant | VISO_Max(VRMS) | VDRM_Max(V) | IFT_Max(mA) | dv/dt(V/μs) | TOPR(°C) | JJM Package |
|---|
| JOC303XD4 | X = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-4, SMD-4 |
|---|
| JOC304X | X = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-6, SMD-6 |
|---|
| JOC306XM4 | X = 1, 2, 3 | 3750 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | SOP-4 |
|---|
| JOC305XD4 | X = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-4, SMD-4 |
|---|
| JOC307X | X = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-6, SMD-6 |
|---|
| JJOC301XM4 | X = 0, 1, 2 | 3750 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | SOP-4 |
|---|
| Product Name |
Data Transfer Rate(Mbit/s) |
CTR_Min （%） |
CTR_Max （%） |
TPHL_Max(μs) | TPLH_Max(μs) | CMH/L_Min(V/μs) | VISO_Max(VRMS) | JJM Package |
|---|
| 6N138 | 0.1 | 300 | 2000 | 10.0 | 35.0 | 1000 | 5000 | DIP-8, SMD-8 |
|---|
| 6N139 | 0.1 | 500 | 2000 | 1.0 | 7.0 | 1000 | 50 | DIP-8, SMD-8 |
|---|
| Product Name |
IO_Max(A) | ICCH/L_Max(mA) | VCC_Max(V) | TPHL_Max(μs) | TPLH_Max(μs) | CMH/L_Min(kV/μs) | VISO_Max(VRMS) | JJM Package |
|---|
| JOC3120R | 2.5 | 3 | 15 ~ 35 | 200 | 200 | 20 | 5000 | DIP-8, SMD-8 |
|---|
| JOC314 | 0.8 | 3 | 10 ~ 30 | 110 | 110 | 20 | 5000 | DIP-8, SMD-8 |
|---|
| JOC341 | 3 | 3 | 10 ~ 35 | 110 | 110 | 20 | 5000 | WSOP-6 |
|---|
| JOC343 | 4 | 3 | 10 ~ 35 | 110 | 110 | 20 | 5000 | WSOP-6 |
|---|
| Product Name |
IT(RMS)_Max(A) | ITSM_Max(A) | VDRM / VRRM_Max(V) | IGT_I_Max (mA) | IGT_II_Max(mA) | IGT_III_Max (mA) | IGT_IV_Max(mA) | TJ (°C) | JJM Package |
|---|
| JST131U-800D | 1 | 16 | 800 | 5 | 5 | 5 | 10 | 125 | TO-92 |
|---|
| JST137C-800E | 8 | 65 | 800 | 10 | 10 | 10 | 25 | 125 | TO-220C |
|---|
| Product Name |
Data Transfer Rate(Mbit/s) |
CTR_Min （%） |
CTR_Max （%） |
TPHL_Max(μs) | TPLH_Max(μs) | CMH/L_Min(V/μs) | VISO_Max(VRMS) | JJMPackage |
|---|
| 6N138 | 0.1 | 300 | 2000 | 10.0 | 35.0 | 1000 | 5000 | DIP-8, SMD-8 |
|---|
| 6N139 | 0.1 | 500 | 2000 | 1.0 | 7.0 | 1000 | 50 | DIP-8, SMD-8 |
|---|
| Product Name |
Variant | VISO_Max(VRMS) | VDRM_Max(V) | IFT_Max(mA) | dv/dt(V/μs) | TOPR(°C) | JJMPackage |
|---|
| JOC30X1X2D4 | X1 = 3, 4, 6, 8X2 = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-4, SMD-4 |
|---|
| JOC30X1X2 | X1 = 3, 4, 6, 8X2 = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-6, SMD-6 |
|---|
| JOC30X1X2M4 | X1 = 3, 4, 6, 8X2 = 1, 2, 3 | 3750 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | SOP-4 |
|---|
| JOC30X1X2D4 | X1 = 1, X2 = 0, 1, 2X1 = 2, 5, 7, X2 = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-4, SMD-4 |
|---|
| JOC30X1X2 | X1 = 1, X2 = 0, 1, 2X1 = 2, 5, 7, X2 = 1, 2, 3 | 5000 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | DIP-6, SMD-6 |
|---|
| JOC30X1X2M4 | X1 = 1, X2 = 0, 1, 2X1 = 2, 5, 7, X2 = 1, 2, 3 | 3750 | 250 , 400 , 600 , 800 | 15, 10, 5 | 1000 | -40 ~ 100 | SOP-4 |
|---|
| Product Name | Rank | CTR_Min (%) |
CTR_Max (%) |
IF_Max(mA) | VR_Max(A) | VCEO_Max(V) | VISO_Max(VRMS) | JJMPackage |
|---|
| JOC816X1 | A | 80 | 160 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| B | 130 | 260 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| C | 200 | 400 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| D | 300 | 600 | 60 | 6 | 80 | 5000 | DIP-4, SMD-4 |
|---|
| JOC817X1 | - | 50 | 600 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| A | 80 | 160 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| B | 130 | 260 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| C | 200 | 400 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| D | 300 | 600 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| E | 100 | 200 | 60 | 6 | 35 | 5000 | DIP-4, SMD-4 |
|---|
| JOC101X | 1010 | 300 | 600 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1015 | 50 | 150 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1016 | 100 | 300 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1017 | 80 | 160 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1018 | 130 | 260 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1019 | 200 | 400 | 5 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1011 | 60 | 300 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1012 | 63 | 125 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1013 | 100 | 200 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1014 | 160 | 320 | 10 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1012 | 22 | - | 1 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1013 | 34 | - | 1 | 6 | 80 | 5000 | LSOP-4 |
|---|
| 1014 | 56 | - | 1 | 6 | 80 | 5000 | LSOP-4 |
|---|
